Product Name: Nanocrystalline Core Toroidal Transformer Core for High-power Transformers
Description: SWITCH POWER NANOCRYSTALLINE CORES Nanocrystalline core for high-power transformers Transmart Part number Core dimensions Weight mFe g Permeability ( µ at 10kHz ) AL 10 kHz 100 kHz nominal μH Saturation current typical 10 kHz 100 kHz A Case material PBT (130℃) Core dimensions da x di x h mm x mm x mm Finished core size OD ID H mm x mm x mm Specified value Design refer NH-0002 50x32x20 54x28x24 125.0 65600 ≤ µ` ≤ 127000 87,000 25.5 6.4 0.2 0.4 PBT NH-0003 64x40x20 66x37x23 215.0 72000 ≤ µ` ≤ 139000 97,000 28.0 6.8 0.2 0.4 PBT NH-0004 70x40x20 75x36x25 265.0 42200 ≤ µ` ≤ 81500 56,000 10.0 3.6 0.4 0.8 PBT NH-0005 70x40x25 72x37x28 352.0 72000 ≤ µ` ≤ 139000 94,000 27.0 6.7 0.3 0.5 PBT NH-0006 80x50x25 85x44x30 416.0 PBT NH-0010 100x50x25 105x45x44 805.0 72000 ≤ µ`≤ 135000 97,000 43.0 10.1 0.3 0.6 PBT NH-0011 100x60x20 105x56x23 540.0 18000 ≤ µ` ≤ 35000 23,700 11.7 6.5 1.2 1.7 PBT NH-0014 105x60x30 110x57x35 957.0 72000 ≤ µ` ≤ 135000 96,000 30.0 6.9 0.3 0.7 PBT NH-0015 105x60x40 110x57x34 1267.0 72000 ≤ µ` ≤ 130000 96,000 36.1 8.8 0.4 0.7 PBT NH-0018 110x60x20 116x55x25 725.0 72000 ≤ µ` ≤ 135000 97,000 55.2 13.6 0.4 0.7 PBT NH-0019 110x60x25 115x54x30 907.0 18100 ≤ µ` ≤35000 23,700 14.3 9.1 1.4 2.1 PBT NH-0020 110x60x30 115x55x35 1081.0 60000 ≤ µ` ≤ 116000 80,000 28.4 7.3 0.6 1.1 PBT NH-0021 120x60x30 125x57x35 1384.0 72000 ≤ µ` ≤ 135000 95,000 65.5 15.5 0.4 0.9 PBT NH-0022 120x70x20 125x67x25 811.0 15000 ≤ µ` ≤ 35000 24,300 17.0 11.5 1.7 2.6 PBT NH-0023 120x70x25 125x67x30 1014.0 3300 ≤ µ` ≤ 6400 ( 100kHz ) 4,400 3.2 3.1 9.3 9.6 PBT NH-0024 120x70x30 125x67x35 1217.0 72000 ≤ µ` ≤ 135000 103,000 59.3 14.0 0.5 1.0 PBT NH-0025 120x70x40 125x67x47 1538.0 72000 ≤ µ` ≤ 135000 25,500 15.5 11.1 2.1 3.1 PBT NH-0026 130x80x40 136x76x45 1793.0 3280 ≤ µ` ≤ 6400 ( 100kHz ) 4,400 2.9 2.8 11.4 11.8 PBT NH-0027 130x80x50 136x76x55 2242.0 72000 ≤ µ` ≤ 135000 96,000 88.0 20.0 0.5 1.1 PBT NH-0029 130x90x50 136x85x56 1879.0 72000 ≤ µ` ≤ 135000 95,000 47.2 11.1 0.8 1.5 PBT NH-0035 80x50x20 85x44x25 332.0 15000 ≤ µ` ≤ 29000 20,000 12.2 7.9 3.7 5.1 PBT NH-0037 130x80x60 136x76x66 2700.0 3160 ≤ µ` ≤ 6300 ( 100kHz ) 4,300 2.3 2.2 16.6 17.1 PBT NANOCRYSTALLINE CORE FOR HIGH-POWER TRANSFORMERS Nanocrystalline based on nanocrystals less than 10 nanometer in their structure, therefore cores made by nanocrystalline are much superior than the other soft magnetic materials. APPLICATIONS Inverter welding equipments X-ray, laser, communication power supplies / UPS High frequency induction heating power supplies / Charging power supplies Frequency control of motor speed power supplies Plasma cutting machines Features Higher permeability Lower magnetization in higher inductions Low core losses especially at high frequencie Less losses on high temperatures
Category: Nanocrystalline Cores
Contact Us for Quote
For more product information or latest pricing, please contact us.
